Rated

Vtage

(WVDC)

Capacitance

(uF)

Global

Part Numbert

Nominal

Case Size

DxL(inches)

Case

Size

Code

Maximum ESR

Rated

Ripple Current

450 Volts 500 Volts Surge

150

E36D451HPN151MA41M

1.375  1.625

A41

1,687.8

0.96

270

E36D451HPN271MA54M

1.375  2.125

A54

923.3

1.39

330

E36D451HPN331MA67M

1.375  2.625

A67

749.9

1.60

470

E36D451HPN471MA79M

1.375  3.125

A79

525.5

2.05

560

E36D451HPN561MA92M

1.375  3.625

A92

440.3

2.40

680

E36D451HPN681MAA5M

1.375  4.125

AA5

362.5

2.81

820

E36D451HPN821MAB7M

1.375  4.625

AB7

300.7

3.16

1,000

E36D451HPN102MAE3M

1.375  5.625

AE3

246.6

3.83

330

E36D451HPN331MC48M

2.000  1.875

C48

653.4

1.73

470

E36D451HPN471MC54M

2.000  2.125

C54

535.9

2.16

680

E36D451HPN681MC67M

2.000  2.625

C67

366.8

2.76

1,000

E36D451HPN102MC79M

2.000  3.125

C79

249.0

3.60

1,200

E36D451HPN122MC92M

2.000  3.625

C92

207.1

4.21

1,500

E36D451HPN152MCA5M

2.000  4.125

CA5

165.8

4.99

1,800

E36D451HPN182MCB7M

2.000  4.625

CB7

138.3

5.74

2,200

E36D451HPN222MCE3M

2.000  5.625

CE3

113.2

6.95

1,500

E36D451HPN152MD79M

2.500  3.125

D79

168.2

5.02

2,200

E36D451HPN222MDA5M

2.500  4.125

DA5

114.5

6.86

2,700

E36D451HPN272MDB7M

2.500  4.625

DB7

93.7

7.97

3,300

E36D451HPN332MDD0M

2.500  5.125

DD0

77.1

9.23

3,900

E36D451HPN392MDE3M

2.500  5.625

DE3

65.6

10.47

2,700

E36D451HPN272ME92M

3.000  3.625

E92

95.6

7.93

3,900

E36D451HPN392MEA5M

3.000  4.125

EA5

78.4

10.08

4,700

E36D451HPN472MED0M

3.000  5.125

ED0

55.7

12.13

5,600

E36D451HPN562MEE3M

3.000  5.625

EE3

47.2

13.80

8,200

E36D451HPN822MEN0M

3.000  8.625

EN0

32.4

20.25

4,700

E36D451LLN472MFA5M

3.500  4.125

FA5

67.0

7.87

5,600

E36D451LLN562MFB7M

3.500  4.625

FB7

56.0

8.94

6,800

E36D451LLN682MFD0M

3.500  5.125

FD0

47.0

10.28
